About This Service

What is a cement sheet partition?

Cement sheet partitions — also called fibre cement board partitions — use pre-manufactured boards composed of Portland cement reinforced with cellulose fibres. These boards are dense, hard, and non-porous, giving them properties that no gypsum-based product can match: true moisture impermeability, non-combustibility, and physical impact resistance. Where a gypsum partition absorbs moisture and deteriorates in wet environments, a fibre cement board simply does not — it is fundamentally the same material as the concrete structure around it, engineered into a flat sheet form.

The partition system uses the same GI stud framework as a standard gypsum partition — floor tracks, ceiling tracks, and vertical studs at regular intervals — but the boards fixed to the framework are fibre cement rather than gypsum. This means the installation process is familiar, but the result is a wall that can withstand conditions that would destroy standard drywall within months: steam, grease, water splash, chemical cleaning, physical impact from carts and equipment, and sustained humidity from Bangalore's monsoon seasons.

Fibre cement boards are available in multiple thicknesses — 6mm for lighter partition applications, 8mm for standard commercial use, and 12mm for high-impact industrial environments. The surface can be left as-is for purely functional spaces, skim-coated and painted for offices and clinics, or tiled directly for kitchen and bathroom applications. All edges and penetrations should be sealed for maximum moisture resistance, particularly in wet zone applications.

Best suited for: Factory partition walls, warehouse office enclosures, commercial kitchen back-of-house areas, car park stairwells and boundary walls, swimming pool changing rooms and shower areas, generator and electrical room enclosures, outdoor storage structures, and any environment where gypsum would fail.

Fibre cement board partition installation showing stud framework and board fixing heavy-duty commercial Bangalore — Elysian False Ceiling

Why Cement Sheet Partition

Why choose a cement sheet partition?

Four properties that make fibre cement board the right partition material when the environment exceeds the tolerance of standard drywall.

01

Superior impact resistance for demanding environments

Fibre cement boards are significantly denser and harder than gypsum. A standard gypsum partition can be dented or punctured by a shopping trolley, forklift tine, or heavy equipment. A cement sheet partition of equivalent thickness absorbs such impacts without surface damage. In factory floors, car parks, and commercial kitchens where walls are routinely struck by carts, equipment, and vehicles, this impact resistance is not a luxury — it is the reason the partition still looks presentable two years after installation rather than showing dents and holes.

02

Completely moisture-proof in any environment

Gypsum board absorbs moisture — slowly in moderately humid rooms, rapidly in direct water contact. Once wet, gypsum softens, loses structural integrity, grows mould, and eventually crumbles. Fibre cement board absorbs virtually no water. It can be sprayed with a hose, exposed to monsoon humidity for decades, or installed in a steam-filled commercial kitchen and remain dimensionally stable and structurally sound throughout. For any partition in a wet or humid environment in Bangalore, the question is not whether to use cement board — it is which thickness and edge treatment is appropriate.

03

Non-combustible throughout — intrinsically fire-safe

Portland cement does not burn. Fibre cement board is classified non-combustible and achieves Class A fire ratings for surface spread of flame without any special treatment or additional fire-resistant layer. In environments where fire safety is a regulatory requirement — generator rooms, electrical switchgear enclosures, restaurant kitchens, and industrial facilities — cement sheet partitions meet the fire safety specification inherently, not through an added fire-rated board upgrade. This simplifies specification and reduces the risk of using the wrong board type for the application.

04

Suitable for semi-outdoor and exposed applications

Fibre cement board is used in building cladding and external wall construction — it is designed to handle weather exposure. In partition applications, this means it is the correct material for covered car parks with wind-driven rain, stairwells open to outdoor air, partially sheltered boundary walls, and any partition that may be exposed to the elements in ways that a conventional indoor partition would not tolerate. No other lightweight partition material performs reliably in these conditions without significant additional weatherproofing treatment.

Materials

Materials and system components

Cement sheet partition systems use the same GI framework as standard partitions, with fibre cement boards specified for the environment and application.

Fibre cement boards (6mm / 8mm / 12mm)

Portland cement reinforced with cellulose fibres, available in multiple thicknesses. 6mm boards are used for lighter partition applications and interior wet walls. 8mm is the standard commercial thickness for most partition applications. 12mm is specified for high-impact industrial environments or where maximum rigidity is required. Board selection is based on the environment, height of the partition, and expected physical loads.

GI stud framework (tracks and vertical studs)

Galvanised iron floor tracks, ceiling tracks, and vertical studs — the same framework system used for gypsum partitions. For cement sheet applications, stud spacing is typically closer (300mm to 400mm centres) due to the greater weight of the boards. All GI components are hot-dipped galvanised and coated to prevent rust in humid environments. For outdoor-exposed applications, stainless steel or aluminium framework options are available.

Mechanical fasteners and edge sealant

Fibre cement boards are fixed with self-drilling screws specifically rated for cement board — standard drywall screws are not adequate. All board edges, penetrations, and joints are sealed with flexible, waterproof joint sealant to prevent moisture ingress at the board boundaries. This edge sealing is critical in wet zone applications — an unsealed edge will allow water to wick into the board over time, compromising the partition's moisture resistance.

Alkali-resistant primer and compatible topcoat

When a painted finish is specified, the cement board surface is first primed with an alkali-resistant primer — essential because the Portland cement in the board creates an alkaline surface that causes conventional paint to fail prematurely. After priming, any standard exterior or interior emulsion can be applied. For tiled applications in wet areas, appropriate tile adhesive is used directly on the board surface without separate priming.

Fibre cement boards and GI stud framework components for cement sheet partition Bangalore — Elysian False Ceiling

How We Work

Our cement sheet partition installation process

Five steps from framework erection to sealed, finished partition wall.

01

Site survey and partition specification

We assess the environment — moisture exposure, physical impact risks, fire safety requirements, and the planned surface finish — and specify the correct board thickness, stud spacing, and edge treatment. For industrial and semi-outdoor applications, this specification stage is more detailed than a standard office partition, as incorrect material choices can lead to premature failure in demanding environments.

02

Framework installation with closer stud centres

GI floor and ceiling tracks are anchored to the structural slab using heavy-duty concrete anchors appropriate for the board weight. Vertical studs are positioned at 300mm to 400mm centres — closer than a standard gypsum partition — to support the increased weight of fibre cement boards and prevent panel flex under impact loads. Framework levelness is verified throughout before boarding begins.

03

Board fixing with cement-board rated screws

Fibre cement boards are cut to size using a score-and-snap method or a masonry blade for cleaner cuts, then fixed to the stud framework using self-drilling screws rated for cement board. Screw spacing follows the board manufacturer's specification — typically 200mm at edges and 300mm in the field. All cut edges are immediately treated with edge sealant to prevent moisture ingress at exposed cement surfaces.

04

Joint sealing and gap filling

All joints between boards, at wall-to-floor and wall-to-ceiling junctions, around door frames, and at any penetrations for pipes, conduits, or electrical boxes are filled and sealed with flexible waterproof joint compound and sealant. For wet zone applications, every joint is treated — any gap in the sealing creates a potential moisture ingress point that will compromise the partition's performance over time.

05

Surface finishing and handover

Depending on the specified finish, the partition is either left as-is for purely functional spaces, primed and painted for offices and clinics, or prepared for direct tiling in wet areas. A final inspection checks all board fixing, joint sealing, and surface preparation before handover. We document the specification used — board type, thickness, and sealing details — for future reference and any maintenance requirements.

Project Gallery

Cement sheet partition projects in Bangalore

A selection of completed cement sheet partition installations across Bangalore industrial and commercial spaces.

Warehouse office cement sheet partition industrial facility Peenya Bangalore — Elysian False Ceiling — Warehouse office enclosure — cement sheet partition with painted finish, Peenya

Factory boundary partition cement board large area industrial Jigani Bangalore — Elysian False Ceiling — Factory boundary partition — 8mm cement boards, large-format industrial installation, Jigani

Car park stairwell cement sheet partition enclosure Sarjapur Bangalore — Elysian False Ceiling — Car park stairwell enclosure — cement board partition with sealed edges, Sarjapur

Restaurant commercial kitchen cement partition tiled finish BTM Layout Bangalore — Elysian False Ceiling — Restaurant kitchen — cement board partition with direct tile finish for hygiene compliance, BTM Layout

Sports facility toilet block cement sheet partition Yelahanka Bangalore — Elysian False Ceiling — Sports facility toilet block — cement partition with tiled finish, moisture zone application, Yelahanka

Generator room enclosure cement sheet partition fire safe painted Hebbal Bangalore — Elysian False Ceiling — Generator room enclosure — fire-safe cement board partition with sealed penetrations, Hebbal

Packages

Choose your package

Every cement sheet partition project is quoted based on partition dimensions, board specification, and environment requirements.

Basic

6mm or 8mm fibre cement board
Standard GI framework
Edge sealing at critical junctions

8-Year Warranty

Best for: Light commercial partitions, storage enclosures, utility area walls

Get a Quote →

Standard

8mm board with fully sealed joints throughout
Closer stud spacing for impact-resistant installation
Alkali-resistant priming and painted or tiled finish

12-Year Warranty

Best for: Commercial kitchens, changing rooms, semi-outdoor partitions

Get a Quote →

Premium

12mm board with double-layer option for maximum impact resistance
Heavy-duty GI or stainless steel framework
Full weatherproof sealing system — all edges and penetrations

15-Year Warranty

Best for: Industrial facilities, pool areas, fully exposed partitions

Get a Quote →

Have a specific industrial or commercial requirement? Chat with us on WhatsApp.

FAQs

Frequently asked questions

Common questions about cement sheet partitions for Bangalore commercial and industrial projects.

What is the difference between cement sheet and gypsum partitions?

Gypsum board is a calcium sulphate core with paper facers — it performs well in dry indoor environments but deteriorates when exposed to sustained moisture or physical impact. Fibre cement board is a Portland cement matrix reinforced with cellulose fibres — dense, non-absorbent, non-combustible, and hard. It handles moisture, impact, and temperature extremes that would damage or destroy a gypsum partition. For dry offices and homes, gypsum is practical. For kitchens, car parks, factories, and semi-outdoor spaces, cement sheet is the correct specification.

Can cement sheet partitions be used in semi-outdoor or exposed environments?

Yes — this is one of the primary applications for cement sheet partitions. Fibre cement boards are manufactured to be weather-resistant and are used in building cladding and wet zones. For partitions, they are the correct material for covered car parks, stairwell enclosures, semi-outdoor storage areas, and any partition exposed to wind-driven rain or condensation. For fully uncovered outdoor applications, appropriate edge sealing and weatherproof coating are required, and we advise on this during the site consultation.

Are cement sheet partitions fireproof?

Fibre cement board is non-combustible — it will not burn or contribute fuel to a fire, achieving Class A fire ratings for surface spread of flame inherently. For applications requiring specific fire resistance ratings stated in minutes (for example, a 60-minute fire-rated partition for a generator room), the system specification — board thickness, stud specification, and any cavity treatment — needs to be designed to the applicable standard. We can specify the correct configuration for your compliance requirements during the consultation.

How thick are cement sheet partitions?

A standard configuration using 6mm boards on each face of a 70mm stud produces a total partition thickness of approximately 82mm. For 8mm boards on a 90mm stud — the standard commercial specification — the total is around 106mm. Twelve-millimetre boards on a 100mm stud produce approximately 124mm total thickness. Double-layer configurations for maximum impact resistance are thicker. Board thickness is selected based on the environment, the height of the partition, and expected physical loads — we specify the correct option during the site consultation.

Can cement sheet partitions be painted or tiled?

Both options are available. Direct tiling onto cement board is one of the most reliable methods for wet area walls — the dense surface provides excellent tile adhesion. For a painted finish, the joint lines need to be taped and filled, and the board surface primed with an alkali-resistant primer before topcoat application, as the Portland cement creates an alkaline surface that causes conventional paint to fail prematurely. The painted surface is robust but requires the primer step for long-term adhesion.

What commercial applications are most suited to cement sheet partitions?

Cement sheet partitions are most commonly specified for: commercial kitchens subject to steam, grease, and wash-down; factory and warehouse walls subject to forklift impact; car park stairwells and boundary enclosures; toilet and shower blocks in sports facilities; generator and electrical room enclosures; outdoor storage structures; and any environment where moisture, impact, or temperature cycles exceed the tolerance of standard gypsum board. If your space has any of these conditions, cement sheet is likely the correct specification — we can confirm during a site visit.
